7.18 Belt Drive
7.18.1 Drive belt – Condition check
Preconditions
☑ Engine is stopped and starting disabled.
☑ Guard is removed.
Drive belt – Condition check
Item Findings Action
Drive belt A Singular cracks None
Drive belt Belt is oily, shows signs of over‐
heating
Replace (→ Page 142)
Drive belt B Cracks on entire circumference
Drive belt C Chunking
138 | Task Description | MW15407/14E 2012-02
TIM-ID: 0000000920 - 009
