MTU 8 V 2000 M70 - 3.8 Main engine dimensions

3.8 Main engine dimensions
Main engine dimensions
Engine model Length (A) Width (B) Height (C)
8 V 2000 M70 approx. 2005 mm approx. 1280 mm approx. 1315 mm
12 V 2000 M70 approx. 2470 mm approx. 1400 mm approx. 1460 mm
16 V 2000 M70 approx. 2815 mm approx. 1400 mm approx. 1520 mm
