Mueller Bakery Chiller, Models PMC 40/50 and PMC 70/120 Effective February 23, 1999
Installation and Operation Manual, Part No. 9842311 Revised October 17, 2019
6.6 CHILLER ASSEMBLY PARTS LIST, MODEL PMC 70/120
15
Item No. No. Required Part No. Description
1 9844604 Chiller, Bakery Model PMC 70/120
1 1 9844345 Pump, Water, Circulating, .75 HP
2 1 9842292 Control Box Assembly
3 1 9842309 Switch, Flow, Magnetic
4 2 9842295 Valve, Solenoid, .75" NPT
5 2 9844350 Vent, Breather, Low Profile,
3
⁄4" MNPT, Brass
6 1 8802042 Tube, Inlet Water
7 1 9844320 Probe, Level
8 1 30041 Clamp, Hose
9 1 8820165 Thermocouple, Sensor, Type “T”
10 1 9844291 Valve, Expansion
11 4 9844344 Leg, Assembly
12 1 30478 Distributor
13 1 9843187 Regulator Flow .75", 10 gpm
To Next Page
