Mueller Bakery Chiller, Models PMC 40/50 and PMC 70/120 Effective February 23, 1999
Installation and Operation Manual, Part No. 9842311 Revised October 17, 2019
7.6 THERMAL EXPANSION VALVE SUPERHEAT ADJUSTMENT DIAGRAM
19
TEV Sensing Bulb
Thermometer
Suction Gauge
Liquid Line
Sight Glass
Liquid Line
Service Valve
Suction Line
Service Valve
Bakery Chiller
Air-Cooled Condensing Unit
Suction Line
Liquid Line
CR0011
Thermostatic
Expansion Valve
