MD-1000I / MD-2000I / MD-3000I Explanation of USB Function

12 2 3455678

999101011

3.2.3 MD-3000I

1 USB port

2 Fan

3 Battery pack connector

4 Circuit breaker for two programmable outputs

5 Circuit breaker for two non-programmable outputs

6 Power input circuit breaker

7 Power input

8 Communication interface

9 UPS output (non-programmable)

10 UPS output (programmable)

11 Emergency power off (EPO) port

12 RS-232 port

Fig. 3-2 - 5 MD-3000I rear panel
