Multiplex ROXXY MSB 70A User Manual

3
Contents
Congratulations on your purchase of the new ROXXY Smart Control brushless speed controller. We are delighted
that you have chosen a product from the MULTIPLEX range. The ROXXY Smart Control speed controller provides
all the usual basic functions, but it also offers the facility to generate a great deal of data - including voltage,
current, temperature, rotational speed and residual capacity - and pass the information to your MULTIPLEX
transmitter via the MULTIPLEX SENSOR BUS (MSB). As of now the ROXXY Smart Control is the ECG (electro-
cardiogram) for your electric motor!
1. Introduction ...................................................... 3
1.1 Special features ................................................ 3
1.2 Specication ............... ...................................... 4
1.3 Approved usage ................................................ 4
1.4 Safety notes ............ ......................................... 5
2 Connections ..................................................... 6
3. Basic settings ................................................... 7
4. Safety functions .. ............................................... 8
5. Preparation ....................................................... 9
6. First use ................. ...................................... 10
7. Conguration ................................................. 11
8. Model type specic settings ............... ............. 15
8.1 Heli mode ...................................................... 15
8.2 Car / boat Mode ............................................. 16
9. Trouble-shooting ........................................... 17
10. Accessories .................................................. 18
10.1 Guarantee / liability ......................................... 19
10.2 Conformity declaration / disposal ......................19
1. Introduction
1.1 Special features
The speed controllers in the ROXXY Smart Control
range include a series of innovative features:
· Integral PC interface
Convenient set-up using MULTIPLEX Launcher (USB-
lead # 8 5149 required).
· Integral sensors for measuring voltage, current, bat-
tery charge (residual battery capacity), temperature
and rotational speed (rpm).
· User-variable alarm thresholds for voltage, charge
(residual battery capacity) and rotational speed
(rpm).
· Automatic / manual reset of the charge counter
· BEC voltage variable by software in 0.1V increments
(5.0 ... 8.0V).
· Governor mode, optionally with Governor Stabilize.
· Car / boat mode (forward / reverse function).
· User-variable motor timing ( 0 .. 25°).
· User-variable start-up torque (5 stages).
· User-variable soft-start (5 stages).
· User-variable motor pole count (2 - 32).
· User-variable brake power (4 stages).
· Reversal of motor rotation.
Safety functions:
· Start-up guard - motor only starts when controller
detects Idle position.
· Automatic cell count detection in LiPo mode.
· User-variable cut-off voltage in NiMH mode.
· Low-voltage response: motor speed reduction or
motor cut.
· Telemetry warning if permissible motor current is
exceeded.
· Telemetry warning if permissible temperature
(>100°C) is exceeded.
· Safety motor cut-off at excessive temperature
(>125°C).
· User-variable alarm thresholds for low cell voltage,
maximum rotational speed and battery charge state.
