WTB-16PD TRACK-DRIVE POWER BUGGY • OPERATION MANUAL — REV. #0 (08/31/20) — PAGE 47
HYDRAULIC HOSE CONNECTIONS 2
TO
DUMP VALVE
HYDRAULIC OIL
RETURN FILTER
10 MICRON
HYDRAULIC
OIL TANK
HYDRAULIC OIL
COOLER
GEAR PUMP
G
H
I
F
