MULTIQUIP WTB-16PD - Electrical Wiring Diagram

PAGE 50 — WTB-16PD TRACK-DRIVE POWER BUGGY • OPERATION MANUAL — REV. #0 (08/31/20)
ELECTRICAL WIRING DIAGRAM
BK
Y
B/Y
FEMALE
BK
Y
BU
B/Y
MALE
HONDA HARNESS
FUEL CUT-OFF
SOLENOID
17 AMP
CHARGE COIL
GR
CHASSIS
GND.
M
CHASSIS
GND.
BATTERY
POSITIVE
NEGATIVE
CHASSIS
GND.
+12VDC
GR
B/Y
GND. SIGNAL BLK
STARTER
MOTOR
SOLENOID
5
24
B/Y
6
8
BU
RED
H
+12VDC BLK/YEL
NC
NC
21
2 1
BLK (B)
ENGINE
GND. POINT
30 87A
SPLICE
+12VDC YEL
GND. BLUE
YEL
YEL
EMERGENCY
STOP SWITCH
SPLICE
BR
SPLICE
SPLICE
B/Y
BLK/YEL
WHT
+12VDC
IGN.
START
IG
BAT LO ST
GND
OFF
ON
ST
COMBINATION SWITCH
CONTINUITY
ST
LO
BATT.
GND.
IGN.
HOUR
METER
B/Y
CONTROL BOX
IGNITION
SWITCH
J1
VOLTAGE
REGULATOR
RECTIFER
GR
GR
W/Bu
B/Y
W
B
P1
G
GRN
G (GRN)
BU (BLUE)
B/W
30 AMP.
FUSE
W
B/Y (BLK/YEL)
Y (YEL)
+12VDC WHT
NC
BLK
WHT
BLK/YEL
GRAY
GRAY
BLK
1
2
3
12
16
CONTROL BOX
GND. POINT
ENGINE
GND. POINT
ENGINE
GND. POINT
85
86
K1
HEAT EXCHANGER
RELAY COIL
ENERGIZED
DURING CRANKING
CYCLE ONLY
13
GND. BLUE
+12VDC RED
1
BLK/YEL
BLK
DIODE
BLK/WHT
BLK (A)
BLK (B)
BLK (A)
CONTROL BOX
SIDE
ENGINE
SIDE
21
4 7
10
11
9
14
SPLICE
