Video Grabber DisplayPort User Manual - ver. 1.2
5
2. Device connection ports description
2.1. Front Panel
Figure 1. Front panel
Table 1. Front panel elements
Item
Description
SD Card
Used for firmware update
USB
Used for firmware update and diagnostics
Reset
Used to restart Video Grabber
Screen
Displays information about video signal, network configuration and protocol used
