MULTISPAN AVF-19N - Technical Specifications; Model, Display, and Input; Wiring, Protection, and Environment; Wiring Connection Mode

Power Supply
Operating
Temperature
Wiring
System
Relative
Humidity
0°C To 55°C
3Ph-4W, 3Ph-3W, 1Ph-2W
Up to 95% RH Non Condensing
0.5 To 5Amp AC direct or C.T
Selectable upto 6000/5 ratio
Model
Size (mm)
Display
Panel Cutout
Voltage Input
Current Input
96(H) X 96 (W) X 50 (D) mm
3 Digit/Line 7 seg 0.56”,red LED Display
92 X 92 mm
AVF-19N
50 To 500V AC P-P CAT III
30 To 300V AC P-N CAT III
Protection
Level
(As per request)
IP-65 (Front side) As per IS/IEC 60529 : 2001
TechnicalSpecification
To save changes,
power off the Instrument
Press Scroll Key for 5
seconds with power on the instrument.
RY
YB
BR
A
Hz
V
AVF 19N
3 p h
3 w
C o n
RY
YB
BR
A
Hz
V
AVF 19N
C o n
1 p h
2 w
Press key &
release to select
connection type from
3P/4W,3P/3W,1P/2W
WIRINGCONNECTIONMODE
RY
YB
BR
A
Hz
V
L1
L2
L3
C o n
3 p h
4 w
AVF 19N
RY
YB
BR
A
Hz
V
C o n
3 p h
3 w
AVF 19N
RY
YB
BR
A
Hz
V
C o n
1 p h
2 w
AVF 19N
www.multispanindia.com
Page-1
AVF-19N
100 To 250V AC,50/60 Hz, Approx 4VA
L1
L1
L2
L2
L3
L3
