Page-5
AVF-19N
MODEL
A
96mm 96mm
92mm
92mm 3mm 50mm 53mm
B
C
D E
F
G
DIMENSIONS
MechanicalDimensions
F
D
E
A
B
RightSideView
TopView
G
B
