MULTISPAN AVF-19N - Run Mode Selection; Mode Switching and Navigation; Connection Diagram; Terminal Connections and System Details

ConnectionDiagram
www.multispanindia.com
Page-3
AVF-19N
Press & hold key
for 3 sec & release to
change Auto mode to
Manual mode and
same for Manual mode
to Auto mode
1) In auto mode, scan time is 5sec
2) In auto or manual mode to change parameter page, press key and release.
3) To change from auto to manual & manual to auto, press key for 3 sec & release.
Runmodeselection
RY
YB
BR
A
Hz
V
AVF 19N
4 1 5
5. 0 0
4 9. 9
RY
YB
BR
A
Hz
V
AVF 19N
4 1 5
4 1 5
4 1 5
RY
YB
BR
A
Hz
V
4 1 5
4 1 5
4 1 5
AVF 19N
RY
YB
BR
A
Hz
V
L1
L1
L2
L2
L3
L3
4 1 5
5 0 0
4 9 9
AVF 19N
1
2
3
4
7
8
9
12
13
14
10
11
5
6
S1 S1 S1 S2S2S2
L1
L2
L3
VL1
VL2
VL3
N

100-250VAC
50/60Hz,3VA
L
N
!
3Ø-4W / 3Ø-3W /
Accuracy Class: 1.0
Range:
System:
Current: 0.5 To 5A AC, CAT III
Voltage(L-L) : 50-500V AC, CAT III
(L-N) : 30-300V AC, CAT III
1Ø-2W
CT Selection up to 6000/5 Amp AC CAT III
1920
17
18
16
15
IP-65
MadeinIndia
