Multitech MultiConnect Cell - Power Measurements

HARDWARE INFORMATION
MultiConnect
®
Cell MTC-MNG6 User Guide 13
Power Measurements
Multi-Tech Systems, Inc. recommends incorporating a 10% buffer into your power source when determining
product load.
Serial Model: MTC-MNG6-B01 Power Draw
Radio
Protocol
Sleep Mode
Current
Cellular
Connection
Idle, No Data
Live
Connection
Idle Current
Average
Current at
Max Power
Average TX
Pulse
Amplitude
Current
Total Inrush
Charge
Total Inrush
Charge
Duration
During
Powerup
9 Volts
LTE
707.5
MHz
Band 12
6 mA 23 mA 23 mA 191 mA 452 mA 0.103 mC 9.0 mS
GSM
850 MHz
8 mA N/A 24 mA 158 mA 1.11 A 0.103 mC 9.0 mS
12 Volts
LTE
707.5
MHz
Band 12
5 mA 16 mA 22 mA 149 mA 308 mA 0.076 mC 7.3 mS
GSM
850 MHz
6 mA N/A 12 mA 239 239 0.076 mC 7.3 mS
24 Volts
LTE
707.5
MHz
Band 12
3 mA 12 mA` 13 mA 87 mA 140 mA 0.103 mC 7.4 mS
GSM
850 MHz
4 mA N/A 12 mA 86 mA 432 mA 0.103 mC 7.4 mS
USB Model: MTC-MNG6-B03 Power Draw
Radio
Protocol
Sleep Mode
Current
Cellular
Connection
Idle, No Data
Live
Connection
Idle Current
Average
Current
at Max
Power
Average TX
Pulse
Amplitude
Current
Total Inrush
Charge
Total
Inrush
Charge
Duration
During
Powerup
5 Volts
