MT5600ZDX Owner's Manual
62
Register Unit Range Default Description
S82 - Break Handling Options
S82 is for compatibility purposes only, changing this register will not have any
affect.
S86
decimal 0, 4, 5, 9, 12, 13, or 14 When the modem issues a NO CAR-
RIER result code, a value is written
to this S-Register to help determine
the reason for the failed connection.
S86 records the first event that con-
tributes to a NO CARRIER mes-
sage. The cause codes are:
S86=0 Normal disconnect, no error occurred.
S86=4 Loss of carrier.
S86=5 V.42 negotiation failed to detect an error-correction
modem at the other end.
S86=9 The modems could not find a common protocol.
S86=12 Normal disconnect initiated by the remote modem.
S86=13 Remote modem does not respond after 10 re-
transmissions of the same message.
S86=14 Protocol violation.
S91
dBm 0 to -15 dB 10 Sets the transmit attenuation
level from 0 to 15 dBm for the PSTN
mode, resulting in a transmit level
from 0 to -15 dBm, In some coun-
tries, the transmit level may not be
changed and there are checks to
prevent transmit attenuation level
change. -10 dBm is the transmit
level default.
S92
dBm 0 to -15 dB 10 Sets the transmit attenuation
level from 0 to 15 dBm for the FAX
mode, resulting in a transmit level
from 0 to -15 dBm. In some coun-
tries, the transmit level may not be
changed and there are checks to
prevent transmit attenuation level
change. -10 dBm is the transmit
level default.
