IMC01 Maintenance Manual
Version 1.03
Figure 2-8 Lower Sensors
4) Clean the upper CIS with cleaning cloth.
Figure 2-9 Upper CIS Sensor
Note: For the CIS sensors, it is recommended to used cleaning cloth to clean them.
Lower CIS
Lower UV
UUUUU
Upper CIS
