Muncie ADVANTAGE + - HYDRAULIC CONFIGURATIONS; Mechanically Locked Plow

15
HYDRAULIC
Mechanically Locked Plow
To allow the plow angle to free wheel for a mechanically locked plow, perform the following:
1. Locate CB1 and CB2 valves shown above
2. Loosen the lock-nut and use the appropriate Allen to turn both stems fully CW. This will take the pressure setting from
2750 PSI to 200 PSI.
3. Tighten the lock-nut
HYDRAULIC CONFIGURATIONS
CB1
CB2
