Muncie ADVANTAGE + - Hydraulic Specifications

4
HYDRAULIC SPECIFICATIONS
HYDRAULIC PRESSURE SETTINGS
FUNCTION DESIGNATION DEFAULT PSI* RANGE - PSI ADJUSTED
Main Relief TS3
2200 1500 - 3000 Electically
Clipper Relief RV2
1600 300 - 3500 Mechanically
Boost RV1
200 0 - 500 Mechanically
Spreader
RV3
1600 300 - 3500 Mechanically
Plow Up
RV5
2000 300 - 3500 Mechanically
Plow Down
TS2
600 0 - 1000 Electically
Hoist Up
RV4
2500 300 - 3500 Mechanically
Hoist Down
TS1
600 0 - 1000 Electically
FUNCTION MAX FLOW RATES** DIFFERENTIAL PSI
Inlet Flow 50 GPM
200
Plow Up 15 GPM
200
Plow Down 23 GPM
200
Plow Angle
23 GPM
200
Hoist Up
32 GPM
200
Hoist Down
32 GPM
200
Spinner 15 GPM
200
Auger 15 GPM
200
