Muncie ADVANTAGE + - Page 7

7
DESIG PART NUMBER FUNCTION LOC. DESIG PART NUMBER FUNCTION LOC.
TS3 NXTS38-20AM-0-N-00 Main Relief Front
EP2 NXEP16-S35-0-N-40 Compensator Top
TS1 NXTS12-36C-0-N-0 Hoist Downside Relief Top
EP1 NXEP10-S35-0-N-10 Compensator Right
TS2 TS10-36C-0-N-0 Plow Downside Relief Right
EP3 NXEP10-S35-0-N-10 Compensator Top
SP4 NXSP16-20M-0-N-00 Hoist Raise Top
EP4 NXEP10-S35-0-N-10 Compensator Top
SP5 NXSP16-20M-0-N-00 Hoist Lower Top
EH1 NXEHPR98-T33-0-N-12ER Plow Right Pilot Ctrl Front
SP6 NXSP12-20M-0-N-00 Plow Lower Top
EH2 NXEHPR98-T33-0-N-12ER Plow Left Pilot Ctrl Front
SP2 NXSP10-20AM-0-N-00 Auger Top
CV6 NXCV16-20-0-n-05 Hoist Load Hold Check Left
SP3 NXSP10-20M-0-N-00 Spinner Top
CV8 NXCV10-20-0-N-15 Spreader Check Top
SP1 NXSP10-20M-0-N-00 Plow Raise Right
CV9 NXCV10-20-0-N-15 Spreader Check Front
RV5 NXRV10-22A-0 Plow Raise Relief Top
CV1 NXCV10-20-0-N-05 Check Valve Top
RV4 RV10-22A-0-NC-05-02 Hoist Raise Relief Top
CV2 NXCV06-B20-0-5 Load Sense Check Front
RV3 RV10-22A-0-N-35-XX Spreader Relief Top
CV3 NXCV06-B20-0-5 Load Sense Check Front
RV2
RV10-22A-0-N-35-XX
Clipper Relief Front
CV4 NXCV08-B20-0-4 Load Sense Check Front
RV1
NXRV08-20A-0-NC-05-02
Boost Pressure Relief Front
CV5 NXCV08-B20-0-4 Load Sense Check Front
OR1
NX6101025
Orifice Front
CV7 NXCV08-B20-0-4 Load Sense Check Front
OR2
NX6101025
Orifice Front
CV10 NXCV08-B20-0-4 Load Sense Check Front
OR3
NX6101025
Orifice Front
CV11 NXCV08-B20-0-4 Load Sense Check Front
OR4
NX6101025
Orifice Front
CP3 NX6103116 Hoist Isolation Cavity Left
PE2
NXPE16-S67K-0-N
Plow Angle Spool
Right CP2 NXCP16-20-N Hoist Lower Check Top
CL1
4303712
Coil
CP1 NXCP12-4L-N Aug Rev Cavity Plug Top
FR1
FR08-20F-0-N-/ 0.20
LS Drain Cartridge
Left CB1 NXCBEA-LAN Plow Lt Counterbalance Front
EV1
NXEV16-S34-0-N-10
Unloader
Front CB2 NXCBEA-LAN Plow Rt Counterbalance Front
HYDRAULIC
CARTRIDGE DESIGNATIONS, FUNCTIONS, AND PART NUMBERS
