Munters MCS300 User Manual

MCS300
Openairowsystem
Thedehumidierisplacedoutsidetheareatobedehumidied.Dryairistransportedwithductingtothe
spacetobedehumidiedandthewetairisdischargedinthevicinityoftheunitormovedoutdoors,see
Figure3.3.
Theinstallationisusedtosolvethefollowingproblems:
-Whenmoisturedamagedobjectsaretobedehumidied.
-Dustorcorrosioncausingparticlesarepresentinaspacewheredryairwillbesupplied.
-Topreventmoisturefromenteringthedehumidiedspace/object.
0 1
A
B
G
E
F
D
C
Figure3.3Installationinanopenairowsystem
A.DryairE.Wetair
B.ProcessairF.Reactivationair
C.Connectiontting
1)
G.Connectiontting
2)
D.Surplusair
1)
Fittingwithdiameter80mm(forexample,LindabSafeNPUnippleoralternateLindabDamperDRU80).
2)
Fittingwithdiameter125mm(forexample,LindabSafeNPUnipple).
3.9Electricalconnections
3.9.1General
Includedwithdeliveryisa3.5mlongpowercablewithaplugforconnectiontoanearthedoutlet.The
voltageandfrequencyarespeciedontheunit’sidenticationplate.
3.9.2Safety
W W
W
ARNING! ARNING!
ARNING!
Theunitmustbeconnectedtoanearthedelectricaloutlet.
W W
W
ARNING! ARNING!
ARNING!
Theunitmustnotbeconnectedtoothermainsthanspeciedontheunit’sidenticationplate
9Installation190TEN-1027-F1404
