3.10Connectingthehumidistat
3.10.1General
Theconnectionsocketforthehumidistatislocatedinthestoragecompartmentforthepower
cable,seeFigure3.4.Theappropriateplugforthehumidistatisdeliveredwiththeunit,seesection
3.10.2,Humidistatconnectionkit.Thehumidistatshallbemounted1–1.5m.abovetheoorandpositionedso
thatitisnotexposeddirectlytodryairfromtheunitorincomingmoistairfromopeningandclosingdoors.
Itshouldnotbeplacedclosetoaheatsource,orsothatitisexposedtodirectsunlight.Thehumidistatshall
beasinglestagehumidistatandconnectedsothatthecontrollingcircuitclosesasrelativehumidityincreases.
Theconnectingcableshallbescreenedandhavecopperconductorswithaminimumcross-sectionarea
of2x0.75mm
2
.
0 1
A
Figure3.4Connectionsocketforhumidistat(A)
