MCS300
7Capacitydiagrams
Approximatecapacityinkg/h.Fordetailedinformation,pleasecontactyournearestMuntersofceorrefer
toMunters’DryCapprogram.
0,4
0,8
1,2
1,6
kg/h
3
1
2
°C
-10 0
10
20
30
0
2,0
230V, 50 H z
80 % R H
60 % R H
40 % R H
Figure7.1
0,3
0,6
0,9
1,2
kg/h
3
1
2
°C
-10 0
10
20
30
0
1,5
115V, 50/60 H z
80 % R H
60 % R H
40 % R H
Figure7.2
1.Processairtemperature,ºC2.Processairrelativehumidity,%RH3.Dehumidicationcapacity,kg/h
(moistureremovalkg/hour)
