Thecontrolunitconstantlyreceivesasignalfromthehumiditytransmitter,andcontrolstheairhumidity
byregulatingthepowertotheunitreactivationheaterinoneortwosteps.Intheeventoftwoheatersteps,
abasicstep2/3ofthereactivationoutputisachieved,afterwhich1/3ofthereactivationoutputcanbe
controlledasafollowingstep.
Thecontrolunitisprovidedwithapotentialfreecontacttowhichanexternalalarmdevicecanbe
connected.Theexternalalarmisactivatedtogetherwiththeinternalalarm.
1.3.4Setpointsandcontrolparameters
Checkingandchangingsetpointsandcontrolparameterscanbemadeduringoperationorinstand-bymode.
Figure1.1Operatorpanel
ButtonFunction
Display/changeacertainvalueandresetthealarm
Increasethevalue
Decreasethevalue
%RH:Displaypositionofcontrolstepsforreactivationheater(0=off;1=on).
Duringnormaloperationandinanypositionofthemodeswitchthecurrentrelativeairhumidityis
displayed.
CA CA
CA
UTION! UTION!
UTION!
Damageduetoincorrectadjustmentofthesystemmayinvalidatethewarranty.
