© Munters AB, 2018 21
6 Test menu
Test mode enables you to test various system controls and actions. The following section includes:
•
Relays
•
Feed Scales
•
Poultry Scale
•
Water Pulse
6.1 Relays
This option manually controls each relay.
To control each relay manually:
1. Use the left and right directional arrow keys to move the cursor to the desired relay number you
wish to change.
2. Press the Enter keypad key to toggle the relay on and off.
NOTE The
RFS-6 Broiler
does not operate automatically while in the Relay test mode.
6.2 Feed Scales
The Scales menu item displays the internal machine numbers for the present feed scale readings. If you
know the weight at two points, you can calculate the conversion factors for the load cells.
It also displays the weight in Kg or in Lb for the feed load cell.
6.3 Poultry Scale
The Scales menu item displays the internal machine numbers for the present poultry scale readings. If you
know the weight at two points, you can calculate the conversion factors for the scales. It also displays the
weight in Kg or in Lb for the feed load cell.
6.4 Digital Inputs
The digital inputs are available for sensor input. The display displays ‘0’ for an open input, and ‘1’ for a
short to COM point. Digital Input 1 is connected to the maximum hopper to indicate the maximum filling
of the fill system.
