Munters RFS-6 User Manual

© Munters AB, 2018 7
2 Introduction to the RFS-6 Broiler
The Munters RFS-6 Broiler is a precision broiler feed control system that includes feed and bird scales
enabling the grower to do the following:
•
Precisely control feed delivery
•
Weigh feed delivery results
The RFS-6 Broiler can blend up to three feed sources and deliver feed to four different feed lines. Feed
delivery can be set to preset times for meal time feeding, continuous full feeding, or restricted feeding.
This section details the:
•
Display
•
Control Menu
•
Feeding Curve
•
Keypad Keys
•
Main Menu
2.1 Display
The RFS-6 Broiler normally displays the time, delivered feed for today and growth day. When there is an
alarm the screen alternately displays the alarm message and the standard display. Refer to Figure 1.
Figure 1: Standard Display View
2.2 Control Menu
Press Enter key to view the control menu. Press Menu again and the standard display reappears. Note
the line underneath the quantity. This is the cursor position, and marks the point at which you can make
changes. Refer to Figure 2.
Figure 2: Control Menu
2.3 Feeding Curve
The first item on the control menu is the feeding curve. Press Enter to select the feeding curve. The Menu
key returns to the preceding screen. Refer to Figure 3.
# DAY QTY/BIRD TOTAL
1 1 0.015 205
DAY FEED TIME
009 0.0Kg 13:12
