2-31
2.6 Sensors
2.6.1 Sensor Locations
The following illustration shows the relative positions of the machine’s sensors.
APS
D EXIT
DS3
DS2
HS
OPEN OP
DRS
DS1
TXIL
F COVER
TOS_TC
PES
TEMP
PDS
SWBK
TOS_DC
TRAYS
PRS
OPEN
JAMC2
PSS
PES OP
INTRLCK
HP
*MFX-3595 only
