2-16
2.3.9 Toner transfer mechanism
1
2
3
4
No. Part name No. Part name
1 Toner cartridge 2 Drum cartridge
3 Toner supply route 4 Toner collection route
Cross section
1
2
3
4
No. Part name No. Part name
1 Toner cartridge 2 Drum cartridge
3 Toner discharge opening 4 Toner supply opening
