Maintenance Manual – SC Cutting Plotter
63 AP-74030, Rev / B
6.3.4. EEPROM initialisation and replacement.
Note :
For EEPROM initialisation see ‘Diagnostics with optional LCD keyboard’ Diagnostic 1,
memory, EEPROM.
After initialisation or replacement of the EEPROM the following data may be changed and need to be
reinstalled.
Þ INIT 1 = Settings in normal operation mode = USER parameters such as :
- Speed
- Acceleration
- Force
- Offset
- Shuffle length
- Tool selection
- Page mode
- Replot factor
- Smoothing
- Communication parameters
- Command set (language)
Þ INIT 2 = Adjustments in Diagnostic mode.
- X axis length adjustment
- Cutting mat height measurement
- Knife force calibration
- Sheet-off system adjustment (Not for SC-550)
