Maintenance Manual – SC Cutting Plotter
9 AP-74030, Rev / B
1. SPECIFICATIONS.
1.1. Mutoh SC-series Cutting Plotter
Cutting area SC-550 : 100 – 540 mm x 4 m
SC-650 : 100 – 630 mm x 12 m
SC-750 : 100 – 780 mm x 12 m
SC-1000 : 100 – 1030 mm x 12 m
SC-1300 : 100 – 1200 mm x 12 m
Max. addressable cut length 50 meter
Maximum media thickness 1.2 mm (1 mm for SC-550)
Drive mechanism Friction
Knife / Cut type / principle Drag
Mechanical resolution 0.005 mm
Accuracy 0.15 % (0.20 % for SC-550)
Repeatability 0.15 mm / m
Knife types 30°, 45° 60° Offset 0.3 & 0.5 mm
Speed 1000 mm / s (600 mm / s for SC-550)
Acceleration 4G (pen UP), 3G (pen DOWN)
2G for SC-550
PEN UP / DOWN cycles 40 / sec.
Pressure range 20 – 500 g
Interface (standard) RS – 232 / centronics
Input buffer 1 Mb standard / 4 Mb optional
No optional buffer on SC-550
Graphic languages MHGL, MHGL/2, HGL/2 compatible
& MCGL (Calcomp compatible)
Configurable origin Yes
Offset adjustment range
0 ® 1 mm
Integrated intelligence Fuzzy logic / Vector look-ahead / Curve & Arc
smoothing
Auto sheet off function Yes (not on SC-550)
Replot function Up to 100 copies
Power requirements 100 to 120 VAC 50/60 Hz
200 to 240 VAC 50/60 HZ
