Maintenance Manual – SC Cutting Plotter
83 AP-74030, Rev / B
Ref. Description Partnumber Qty
1 Turn over plate ME-20625 1
2 Transmission plate ME-20626 1
3 Handle plate ME-20624 1
4 Transmission shaft long ME-20663 1
5 Transmission shaft short ME-20664 1
6 Spring DE-45673 1
7 Knob UP/DOWN DE-32254 1
8 Sensor UP/DOWN EY-41760 1
9 Sensor bracket ME-20622 1
10 Clamp shaft DE-44782 4
11 Spacer BR-10010 2
12 Spring washer BR-24650 1
13 Screw M4x16 DR-4001-44611 2
14 Screw M4x30 DR-4001-43920 1
15 Screw M3x8 DR-4001-43329 4
16 Screw M3x6 DR-4005-43728 1
17 Hex. Shaft SC-650 ME-20777 1
17 Hex. Shaft SC-750 ME-20778 1
17 Hex. Shaft SC-1000 ME-20779 1
17 Hex. Shaft SC-1300 ME-21277 1
18 Plastic bearing BR-40010 2
19 E-ring BR-31070 2
