VJ-1324 OPERATION MANUAL 4 Handling the printer
4-25
NOTE
• Do not install the printer in a place that is subject to strong light (sunlight, etc).
Getting strong light on the color measurement may affect the measurement accuracy.
• To use SPECTROVUE VM-10, the printer setting must be as follows.
Make sure the setting before use.
• Media detection: Top & Width or Width
• Output mode: Off or Auto Cut
5.1.6 Output Mode menu
• When the color target is printed on the translucent or colored media, or the media with patterned
indented surfaces, color measurement may not be accurate.
• For details on spectrophotometer (SPECTROVUE VM-10), refer to its operation manual as well.
• When measuring colors, make sure that the color target is dry. If it is not dry enough, the ink may
adhere to the pressurizing rollers of the printer.
1. Connect the printer and computer.
3.7 Connecting the printer to PC
2. Turn the printer ON.
3. Set the media.
3.4 Loading media
4. Set the user type setting.
3.4.3 Setting the User Type Setting
• When the user type setting and media initial operation are complete, "Ready to Print" is
displayed on the operation panel.
5. Start RIP software to print and measure the color target.
NOTE
• For the setting and operations of the RIP software, refer to its operation manual.
• The printer starts printing the color target.
• "Printing" is displayed on the operation panel.
• After printing is complete, "Attaching instrument [ENTER]" is displayed on the operation panel.
To Next Page
