3 Before using VJ-1324 OPERATION MANUAL
3-30
TIP
• Refer to the following for details on each of the print list items.
3.5.1 Nozzle check to 3.5.3 Setup print
6. Repeat step 4 to step 5 when performing test print for other items.
7. Press the [Cancel] key on the operation panel to exit from test print.
• The operation panel returns to Normal.
• The procedure for test printing is complete.
3.5.1 Nozzle check
It is used to check whether there are any clogged heads, or missing or blurred prints.
NOTE
• If the nozzle check result indicates that the checked points are blurred or missing, clean the head.
6.2.3 Head cleaning
Perform the nozzle check once again at the end of the work.
TIP
• Refer to the following for printing procedure.
3.5 Test print
To Next Page
