4. D EVICE CONSTRUCTION
4.1. I NDOOR UNIT
1. Front panel 7. Ionizer generator (if installed)
2. Air filter 8. Deflectors
3. Optional filter (if installed) 9. Emergency button
4. LED display 10. Nominal label
5. Signal receiver
11. Airflow direction louver
6. Terminal block cover 12. Remote controller
4.2. O UTDOOR UNIT
1. Air outlet grille
2. Nominal label
3. Terminal block cover
4. Gas valve
5. Liquid valve
• Note: the above drawings are illustrative drawings.
