MWE LAB EMPEROR XT - OVERVIEW

MWE LAB – EMPEROR XT USER MANUAL - January 2017v1
EMPEROR XT - USER MANUAL
5
*Your Emperor may dier from picture based
on you requested conguraon.
2 OVERVIEW
A
Hidden pre-installed cables
(monitors, USB and power)
B Iron Horse or MWE seat
C
Sand texture polyester
powder paint, scratch
resistant
D
3/16” (6 mm) thick
steel frame
E Hidden subwoofer
2
3
5
4
7
8
6
9
11
1
14
16
10
15
13
A
C
D
E
B
12
1 Front plate logo
2 Front plate
3 Upper secon
4 LED working lights
5 Upper controls
6 Decorave domed accents
7 LED accent lights
8 Monitor mount extenders
9 Back trims
10 Controls
11 Main power AC input
12 Lateral wing
13 Leg rest
14 Cup holder
15 Keyboard tray
16 USB inputs
