MWE LAB EMPEROR XT - CENTER MONITOR; MONITOR MOUNT

To Next Page

To Previous Page

MWE LAB – EMPEROR XT USER MANUAL - January 2017v1

USER MANUAL - EMPEROR XT

6 CENTER MONITOR 7 MONITOR MOUNT

6.1

Install the center monitor on mount using 4x M4 screws. Select the appropriate screw

length. Refer to your monitor user guide for more details about VESA mount installaon.

7.1

Hook up the top of the monitor mount on the designated indents located at the front end

of the top secon.

7.2

Make sure both monitor mount hooks are properly inserted and stable.

2.5mm

Boom of the monitor

M4 (12, 16 or 18mm)
