MWE LAB EMPEROR XT - CENTRAL SECTION (IF APPLICABLE)

MWE LAB – EMPEROR XT USER MANUAL - January 2017v1
USER MANUAL - EMPEROR XT
10
8.1
Hold the aluminum cylinder in place and remove rubber band from belt.
The upper secon has been separated from the central secon to lower down the upper
secon for air shipping. This procedure may not apply to you if the cylinder is already
secured in place.
You may temporarily unghten this screw to
help you move the cylinder in place.
Do not use a cuer, a knife or
any sharp tool, it could damage
the belt and be dangerous.
8.3
Ask a helper to move the upper secon up to allow you to align the cylinder in unused
holes of the upper secon.
8.2
Hold the aluminum cylinder in place and remove screws.
8 CENTRAL SECTION (IF APPLICABLE)
