EMPEROR XT - USER MANUAL
9
7.3
Remove the black strap and plasc hooks holding down the upper secon to the base.
7.5
Place a screw and nut to secure the mount in place.
7.4
Make sure the mount is 100% vercal/upright.
3/16”
X2
Installaon of the retaining screw is essenal before going further in this guide.
5/16-18 x 1
5/16
5/16-18
