5 Maintenance and Inspection
Compound 2-stage Screw Compressor 5.3 Compressor Disassembly Preparation
1612LSC Speed Increaser Type
5-8
P/N Part Name Code No. Remarks Q’ty.
12-1 Gasket, Bearing Head (1)
CS01200-160N 1
12-2 Gasket, Bearing Head (2)
CS01200-1612CN
1
17-2 Gasket, Bearing Cover (2)
CS01700-1612CN
1
23 Gasket, Balance Piston Cover
CS02300-1612CN 1
27-1A Main/Side Bearing (1) A
CS02700-1612C3 1
27-1B Main/Side Bearing (2) B
CS02800-1610C1 1
27-2 Main Bearing (2)
CS02700-125 2
28-1 Main/Side Bearing (1)
CS02800-1610C1 2
28-2 Side Bearing (2)
CS02800-125 2
29-1A Snap Ring (1) A C Type Internal H112 NG11-112
To be replaced if any
abnormality is found.
1
29-1B Snap Ring (1) B C Type Internal H102 NG11-102 3
29-2 Snap Ring (2) C Type Internal H80 NG11-080 4
30 Balance Piston
CS03000-1612C
To be replaced if any
abnormality is found.
1
32 Snap Ring S40 external
NG12-040
To be replaced if any
abnormality is found.
1
33 Balance Piston Sleeve
CS03300-160
To be replaced if any
abnormality is found.
1
35 O-ring JIS B 2401 G95
PA12-095
1
37 Snap Ring C Type Internal H102 NG11-102
To be replaced if any
abnormality is found.
1
38-1A Thrust Bearing (1) A
CS03800-1612CP
1
38-1B Thrust Bearing (1) B
CS03800-160P 1
38-2 Thrust Bearing (2)
CS03800-125P
2
39-1A
Lock Nut (1) A AN14 NG31-014
To be replaced if any
abnormality is found.
1
39-1B
Lock Nut (1) B AN12 NG31-012 2
39-2
Lock Nut (2) AN09 NG31-009 2
40-1A
Lock Washer (1) A AW14 NG32-014 1
40-1B
Lock Washer (1) B AW12 NG32-012 2
40-2
Lock Washer (2) AW09 NG32-009 2
49 O-ring JIS B 2401 G90
PA12-090
1
50 Oil Seal
CS05000-160VD
1
52 Gasket, Seal Cover
CS05200-160N
1
59 O-ring JIS B 2401 P16
PA11-016
1
63 O-ring JIS B 2401 G95
PA12-095
2
65 O-ring JIS B 2401 P75
PA11-075
1
66 Cap Seal BE75
CS06600-125 1
68 Guide Pin Φ3×8
NE2503-008
To be replaced if any
abnormality is found.
1
69 Lock Nut (1) AN05
NG31-005
To be replaced if any
abnormality is found.
1
70 Lock Washer AW05
NG32-005
1
71 Lock Nut AN06 NG31-006
To be replaced if any
abnormality is found.
1
72 Lock Washer AW06 NG32-006 1
73 O-ring JIS B 2401 P21
PA11-021
1
75 O-ring JIS B 2401 G85
PA12-085 1
77 Indicator Cam
CS07700-1610C
To be replaced if any
abnormality is found
1
78 Ball Bearing, Indicator Cam #6000
CS07800-200
1
