2205B0JE-DA-J-N_2014.05.
7 Related Documents
Screw Compressor J-series 7.1 Development View and Configuration Table of the Parts
7-6
Part
No.
Part name
170J
Type, etc.
Part code No. Quantity/unit
Standard
Explosion
proof for
Propane
S M L
487 Plain washer
JIS B 1256, small
dia. M20
1
488 Sheet stopper CS48800-J170 1
489 Valve sheet CS48900-J170 1
490 Valve disc CS49000-J170 1
491 Check valve stem CS49100-J170 1
492 Suction adapter 1
493 Hexagon socket head cap screw M20×50 NB35420-050 8
494 O-ring JIS B2401 P155 PAH80-155 PC11-155 1
528 Sleeve, oil seal 1
529 Hexagon socket set screw M6×8 NA83606-008 2
535 Hexagon socket head cap screw M5×75 NB35405-075 8
536 Spring lock washer
Hexagon socket
head cap screw M5
ND330-05 8
537 Bush, P14 type O-ring CS53700-J170 3
561 O-ring JISB2401 P12 PAH80-012 PC11-012 8
562
Capacity control / variable Vi
solenoid valve
SBL5B-4BL
(UL,CSA)
KK425-1/-2/-3 －
2
SXL6-4BL (CE) －
Dummy block, solenoid valve with bushing －
591 Parallel pin
10 dia.×55 with
female thread
NE2310-055A 2
605-A Plug R1/2 NF06-015 1
605-B Plug R1/2 NF06-015 1
607-A Plug R1/8 NF06-004 1
607-B Plug R1/8 NF06-004 1
611 Sleeve, shower flashing CS61100-J170 1
657 O-ring JIS B2401 G100 PAH81-100 PC12-100 1
658 Retaining ring C type internal JIS B2804 (H100) NG11-100 1
709 Vi position sensor rod housing CS70900-J170 1
711 Spring
O.D 13, wire
diameter 1.6
Free length 100
CS71100-J170 1
712 Vi position sensor rod CS71200-J170 1
713 O-ring JIS B2401 P12 PAH80-012 PC11-012 1
714 O-ring JIS B2401 P6 PAH80-006 PC11-006 1
715 Plug, Vi position sensor rod CS71500-J170 1
716 Retaining ring E type
JIS B2804 E snap
ring 4
NG13-004 1
717 O-ring JIS B2401 G25 PAH81-025 PC12-025 1
718
Gland, Vi position sensor rod
housing
CS71800-J170 1
719 Hexagon socket head cap screw M6×25 NB35406-025 4
720 Vi position sensor support CS72000-J170 1
721 Potentiometer
Midori Precisions
LP-10FB
CS12907
-J1701 1
722 Hexagon socket head cap screw M3×10 NB35403-010 2
723 Hexagon socket head cap screw M6×25 NB35406-025 2
724 Vi position sensor box 1
725 Packing, Sensor box 1
726 Hexagon socket head cap screw M5×15 NB35405-015 4
794 Vi position sensor assembly 1
727 I plug CS72700-J170 1
728 E plug CS72800-J170 1
729 Spring pin 3 dia.×10 NE3203-010 2
731-A Plug R1/8 NF06-004 1
731-B Plug R1/8 NF06-004 1
732-A Plug R1/8 NF06-004 1
732-B Plug R1/8 NF06-004 1
To Next Page
