7 Related Documents
Screw Compressor J-series 7.1 Development View and Configuration Table of the Parts
7-7
Part
No.
Part name
170J
Type, etc.
Part code No. Quantity/unit
Standard
Explosion
proof for
Propane
S M L
732-C Plug R1/8 NF06-004 1
732-D Plug R1/8 NF06-004 1
733-A Plug R1/8 NF06-004 1
733-B Plug R1/8 NF06-004 1
734 Inner cover, balance piston cover CS73400-J170 2
736 Partition plate, suction cover CS73600-J170 1
744 O-ring JIS B2401 G55 PAH81-055 PC12-055 1
745 Rivet 3 dia.×6 4
235-1
Motor spacer For NEMA 44*D CS23502-J170NEMA44
1
Motor spacer For NEMA 50*D CS23502-J170NEMA50
Motor spacer For IEC FF-500 CS23502-J170IEC50
Motor spacer For IEC FF-600 CS23502-J170IEC60
235-2 Plate, motor spacer CS23510-J170 2
235-3 Hexagon socket head cap screw M6×15 NB35406-015 8
739 Hexagon socket head cap screw M16×60 NB35416-060 8
740 Parallel pin
13 dia.×65 with
female thread
NE2313-065A 2
● As for the part code of the O-ring, the material of the standard specification is HNBR
and the material of the explosion-proof for propane specification is FKM.
For O-rings material other than HNBR or FKM, the part code No. are differ depending
on the material.
For customers using O-rings other than the standard material, contact
before purchasing the O-ring.
 The abolition part and so on
The attendant explanation of the abolition part which is shown by the double strikethrough in table
7-1 is as the following table 7-1b
As for the design modification notification (follow-up), refer to 7.4 "Design Modification Notification
(follow-up) " in this chapter.
Table 7-1b
Part
No.
Part Name
Design Modification
Notification (first)
Remarks
Registration
No.
Issue
Date.
34-2 Spring pin 664-055 2012.04.09
Design modification notification
(follow-up) No.C0956-02
35-1 O-ring
664-056 2012.04.09
36 Balance piston hausing
44-1 Thrust bearing gland spacer, M
664-054 2012.03.29
Design modification notification
(follow-up) No.C0957-00
44-2 Thrust bearing gland spacer, F
720 Vi position sensor suppor
t
With the explosion proof
compressors addition, these shift
to the exclusive instruction
manual as No. 794 Vi position
sensor assembly.
721 Potentiometer
722 Hexagon socket head cap screw
724 Vi position sensor box
727 I plug 664-069 2013.10.31
729 Spring pin 664-054 2012.03.29
Design modification notification
(follow-up) No.C0957-00
