Screw Compressor J-series 7.1 Development View and Configuration Table of the Parts
7-10
Table 7-2 Configuration table of the parts of 220J
Part
No.
Part name
220J
Type, etc.
Part code No. Quantity/unit
Standard
Explosion
proof for
Propane
S M L
1
Main rotor casing S 1 — —
Main rotor casing M — 1 —
Main rotor casing L — — 1
2 Hexagon socket head cap screw M16×75 NB35416-075 40
3 Parallel pin
13 dia.x65 with female
thread
NE2313-065A 4
4 Eyebolt M16 NB600-16 2
5 Suction cover 1
6 O-ring JIS B 2401 P450 PAH80-450 PC11-450 1
7 Eyebolt M30 NB600-30 2
9-1 O-ring JIS B 2401 P65 PAH80-065 PC11-065 1
9-2 Back-up ring for O-ring SUN-2BP 65 PBP21-065 2
10-A Plug R3/8 NF06-010 1
10-B Plug R3/4 NF06-020 1
10-C Plug R1/2 NF06-015 1
10-D Plug R1/2 NF06-015 1
10-E Plug R1/2 NF06-015 1
11 Bearing head 1
12 O-ring JIS B 2401 P450 PAH80-450 PC11-450 1
13 Eyebolt M30 NB600-30 1
14 Spring pin 4 dia.×10 NE3204-010 4
15-A Plug R3/8 NF06-010 1
15-B Plug R3/4 NF06-020 1
15-C Plug R3/8 NF06-010 1
15-D Plug R3/8 NF06-010 1
16 Bearing cover 1
17-1 O-ring JIS B 2401 P375 PAH80-375 PC11-375 1
17-2 O-ring JIS B 2401 P14 PAH80-014 PC11-014 1
18-1 Hexagon socket head cap screw M16×60 NB35416-060 5
18-2 Hexagon socket head cap screw M16×90 NB35416-090 9
19 Parallel pin
13 dia.×65 with female
thread
NE2313-065A 2
20 Spring pin 3 dia.×10 NE3203-010 1
21-A Plug R1/8 NF06-004 1
21-B Plug R1/8 NF06-004 1
21-C Plug R1/8 NF06-004 1
21-D Plug R3/8 NF06-010 1
21-E Plug R3/8 NF06-010 1
22 Balance piston cover 1
23-1 O-ring JIS B 2401 G150 PAH81-150 1
23-2 O-ring JIS B 2401 G115 PAH81-115 1
24 Hexagon socket head cap screw M16×60 NB35416-060 13
25
Male rotor S 1 — —
Male rotor M — 1 —
Male rotor L — — 1
26
Female rotor S 1 — —
Female rotor M — 1 —
Female rotor L — — 1
27 Bearing, male rotor Sleeve bearing CS02700-J220M 2
28 Bearing, female rotor Sleeve bearing CS02700-J170M 2
29-1 Retaining ring C type internal JIS B 2804 (H150) NG11-150 2
29-2 Retaining ring C type internal JIS B 2804 (H120) NG11-120 2
30 Balance piston 200*UD CS03000-J220 1
31 Key for balance piston 200*** CS03100-200 1
32 Retaining ring C type external JIS B 2804 (S65) NG12-065 1
33 Sleeve, balance piston 200*UD CS03300-J220 1
34 Spring pin 6 dia.×12 NE3206-012 3 → 2
35-1 O-ring JIS B 2401 P120 PAH80-120 1
To Next Page
