2205B0JE-DA-J-N_2014.05.
7 Related Documents
Screw Compressor J-series 7.1 Development View and Configuration Table of the Parts
7-11
Part
No.
Part name
220J
Type, etc.
Part code No. Quantity/unit
Standard
Explosion
proof for
Propane
S M L
35-2 O-ring JIS B 2401 G150 PAH81-150 PC12-150 1
36 Housing, balance piston CS03600-J220 1
37 Retaining ring C type internal JIS B 2804 (H120) NG11-120 1
38-1
Thrust bearing assembly, male
rotor
7316BEAXT7DF CS03800-J220M 1
38-2
Thrust bearing assembly, female
rotor
7312BEAXT7DF CS03800-J170M 1
39-1 Locknut AN16 NG31-016 1
39-2 Locknut AN12 NG31-012 1
40-1 Lock washer AW16 NG32-016 1
40-2 Lock washer AW12 NG32-012 1
41-1
Thrust bearing outer race spacer,
male rotor
CS04100-J220M 1
41-2
Thrust bearing outer race spacer,
female rotor
CS04100-J220F 1
42-1
Thrust bearing alignment spacer,
male rotor
CS04200-J220M 1
42-2
Thrust bearing alignment spacer,
female rotor
Spacer, alignment male
rotor for 170J*
CS04200-J170M 1
43-1 Thrust bearing gland, male rotor CS04300-J220M 1
43-2 Thrust bearing gland, female rotor CS04300-J220F 1
44-1 Thrust bearing gland spacer, male rotor CS04400-J220M 1
44-2 Thrust bearing gland spacer, female rotor CS04400-J220F 1
45 Hexagon head screw M12×50 NB111012-050 12
46 Conical spring washer
Hexagon head screw
M12
ND320-012 12
48 Retainer for oil seal CS04800-J220 1
49 O-ring JIS B 2401 G145 PAH81-145 PC12-145 1
50 Oil seal SA1J 75 100 13 CS05010-250VD 1
51 Seal cover 1
52-1 O-ring JIS B 2401 G145 PAH81-145 PC12-145 1
52-2 O-ring JIS B 2401 P14 PAH80-014 PC11-014 1
53 Hexagon socket head cap screw M10×35 NB35410-035 8
54
Unloader slide valve S 1 — —
Unloader slide valve M — 1 —
Unloader slide valve L — — 1
58 Hexagon socket head cap screw M8×35 NB35408-035 9
60 Unloader cylinder 1
61 Hexagon socket head cap screw M16×90 NB35416-090 2
62 Hexagon socket head cap screw M16×140 NB35416-140 6
63-1 O-ring JIS B2401 G200 PAH81-200 PC12-200 2
63-2 O-ring JIS B2401 P14 PAH80-014 PC11-014 2
64 Unloader piston CS06400-J220 1
65 O-ring JIS B2401 P170 PAH80-170 PC11-170 2
66 Teflon cap seal SUNR-BE-170 CS06600-J220 2
67 Push rod, unloader slide valve CS06700-J220 1
68 Guide pin PH01NG 5×12 BK NE2505-012 1
69 Locknut AN07 NG31-007 1
70 Lock washer AW07 NG32-007 1
73 O-ring JIS B2401 P44 PAH80-044 PC11-044 1
74 Unloader cylinder cover 1
75-1 O-ring JIS B2401 G175 PAH81-175 PC12-175 1
75-2 O-ring JIS B2401 P14 PAH80-014 PC11-014 1
76 Hexagon socket head cap screw M12×50 NB35412-050 8
77
Unloader indicator cam S CS07700-J220S 1 — —
Unloader indicator cam M CS07700-J220M — 1 —
Unloader indicator cam L CS07700-J220L — — 1
78 Ball bearing #6000 CS07800-200 1
79 Retaining ring C type external JISB2804 (S10) NG12-010 1
80 Bearing gland CS08000-200 1
To Next Page
