2205B0JE-DA-J-N_2014.05.
7 Related Documents
Screw Compressor J-series 7.1 Development View and Configuration Table of the Parts
7-12
Part
No.
Part name
220J
Type, etc.
Part code No. Quantity/unit
Standard
Explosion
proof for
Propane
S M L
81 Hexagon socket head cap screw M6×15 NB35406-015 3
82-1 O-ring JIS B2401 P10A PAH80-010A PC11-010A 2
82-2 O-ring JIS B2401 P16 PAH80-016 PC11-016 1
83 Retainer, O-ring CS8300-170J 1
84 Spacer, unloader cylinder cover CS08400-J170 1
91 Shaft key CS09100-J220 1
100
Mechanical seal assembly
(including 100-1 to 100-5)
CS10002-250EBS 1
100-1 O-ring AS568A-340 PAH82-340 PC62-043 1
100-2 Mating ring 1
100-3 Rotating ring 1
100-4 O-ring AS568A-148 PAH82-148 PC56-148 1
100-5 Hexagon socket set screw M8×9 1
120 Assembly, unloader indicator 1
137 Dial plate, unloader indicator CS13700-J170 1
234 Name plate 1
237-1 Torsional slip washer M CS23700-J220M 1
237-2 Torsional slip washer F CS23700-160 1
246 Guide, unloader slide valve 1
247 Hexagon socket head cap screw M8×90 NB35408-090 4
248 Spring lock washer
Hexagon socket head
cap screw M8
ND330-08 4
249 Parallel pin 8 dia.×80 NE2008-080 2
250-1 Thrust washer, male rotor CS25000-J220 1
250-2 Thrust washer, female rotor CS25000-160 1
267 Spring lock washer
Hexagon socket head
cap screw M8
ND330-08 9
289
Slide valve S, Vi 1 — —
Slide valve M, Vi — 1 —
Slide valve L, Vi — — 1
292
Push rod S, Vi CS29200-J220S 1 — —
Push rod M, Vi CS29200-J220M — 1 —
Push rod L, Vi CS29200-J220L — — 1
293 Spiral retaining ring FRSN-56 NGFR-56 2
294 Piston, Vi CS29400-J220 1
295 O-ring JIS B2401 P65 PAH80-065 PC11-065 1
296 Cylinder, Vi 1
297 Partition plate, unloader cylinder CS29700-J220 1
298 O-ring JIS B2401 G175 PAH81-175 PC12-175 1
299-1 O-ring JIS B2401 G100 PAH81-100 PC12-100 1
299-2 O-ring JIS B2401 G200 PAH81-200 PC12-200 1
325-1 O-ring JIS B2401 P44 PAH80-044 PC11-044 3
325-2 Back-up ring for O-ring SUN-2BP 44 PBP21-044 2
396-1 Liner M for thrust adjustment (Service part)
396-2 Liner F for thrust adjustment 160*** (Service part)
420
Unloader spacer S CS42000-J220S 1 — —
Unloader spacer M CS42000-J220M — 1 —
421 O-ring JIS B2401 P44 PAH80-044 PC11-044 2 —
432 O-ring JIS B2401 G130 PAH81-130 PC12-130 4
433 O-ring JIS B2401 G100 PAH81-100 PC12-100 4
446 Grooved pin
200***
Key for balance piston
CS03100-200 1
451
Push rod gland for unloader slide
valve
CS45100-J220 1
458-1 Plug R3/4 NF06-020 1
458-2 Plug R3/8 NF06-010 4
459 Plug R3/8 NF06-010 1
481 Check valve slider CS48100-J220 1
485 Spring, check valve
O.D 32, wire diameter 2.6
Free length 250
CS48500-J220 1
To Next Page
