Screw Compressor J-series 7.1 Development View and Configuration Table of the Parts
7-13
Part
No.
Part name
220J
Type, etc.
Part code No. Quantity/unit
Standard
Explosion
proof for
Propane
S M L
486 Locknut FU nut FU05SS NG42-05 1
487 Plain washer
JIS B 1256, normal,
product grade C, M24
ND110-24 1
488 Sheet stopper CS48800-J220 1
489 Valve sheet CS48900-J220 1
490 Valve disc CS49000-J220 1
491 Check valve stem CS49100-J220 1
492 Suction adapter 1
493 Hexagon socket head cap screw M22×60 NB35422-060 12
494 O-ring JIS B2401 P220 PAH80-220 PC11-220 1
495 Check valve stem gland CS49500-J220 1
496 Plain washer JIS B1256, normal M12 1
497 Hexagon nut M12 NC30-12 1
528 Sleeve, oil seal 250*** CS52800-250VD 1
529 Hexagon socket set screw M6×8 NA83606-008 2
535 Hexagon socket head cap screw M5×75 NB35405-075 8
536 Spring lock washer
Hexagon socket head
cap screw M5
ND330-05 8
537 Bush, P14 type O-ring CS53700-J170 4
561 O-ring JISB2401 P12 PAH80-012 PC11-012 8
562
Capacity control / variable Vi
solenoid valve
SBL5B-4BL (UL,CSA) KK425-1/2/3 －
2 SXL6-4BL (CE) －
Dummy block, solenoid valve with bushing －
591 Parallel pin
16 dia.×55 with female
thread
NE2313-065A 2
605 Plug R1/2 NF06-015 1
607-A Plug R1/8 NF06-004 1
607-B Plug R1/8 NF06-004 1
607-C Plug R1/8 NF06-004 1
611 Sleeve, shower flashing CS61100-J220 1
657 O-ring JIS B2401 G120 PAH81-120 PC12-120 1
658 Retaining ring C type internal JIS B2804 (H120) NG11-120 1
709 Vi position sensor rod housing CS70900-J220 1
711 Spring
O.D 13, wire diameter 1.6
Free length 100
CS71100-J170 1
712 Vi position sensor rod CS71200-J220 1
713 O-ring JIS B2401 P12 PAH80-012 PC11-012 1
714 O-ring JIS B2401 P6 PAH80-006 PC11-006 1
715 Plug, Vi position sensor rod CS71500-J170 1
716 Retaining ring E type JIS B2804 E snap ring 4 NG13-004 1
717 O-ring JIS B2401 G25 PAH81-025 PC12-025 1
718
Gland, Vi position sensor rod
housing
CS71800-J170 1
719 Hexagon socket head cap screw M6×25 NB35406-025 4
720 Vi position sensor support CS72000-J170 1
721 Potentiometer
Midori Precisions
LP-10FB
CS12907
-J1701 1
722 Hexagon socket head cap screw M3×10 NB35403-010 2
723 Hexagon socket head cap screw M6×25 NB35406-025 2
724 Vi position sensor box 1
725 Packing, Sensor box 1
726 Hexagon socket head cap screw M5×15 NB35405-015 4
794 Vi position sensor assembly 1
727 I plug CS72700-J170 1
728-1 E plug CS72810-J220 1
728-2 E plug gland CS72820-J220 1
728-3 E plug flange CS72830-J220 1
728-4 O-ring JIS B2401 G45 PAH81-045 PC12-045 1
728-5 Hexagon head screw M16×45 NB111016-045 2
