Screw Compressor J-series 7.1 Development View and Configuration Table of the Parts
7-14
Part
No.
Part name
220J
Type, etc.
Part code No. Quantity/unit
Standard
Explosion
proof for
Propane
S M L
731-A Plug R1/8 NF06-004 1
731-B Plug R1/8 NF06-004 1
732-A Plug R1/8 NF06-004 1
732-B Plug R1/8 NF06-004 1
732-C Plug R1/8 NF06-004 1
732-D Plug R1/8 NF06-004 1
733-A Plug R1/8 NF06-004 1
733-B Plug R1/8 NF06-004 1
734-1
Inner cover M, balance piston
cover
CS73400-J280F 2
734-2 Inner cover F, balance piston cover
Inner cover, balance
piston cover for 170J*
CS73400-J170 1
736 Partition plate, suction cover CS73600-J220 1
744 O-ring JIS B2401 G70 PAH81-070 PC12-070 1
745 Rivet 3 dia.×6 4
235-1
Motor spacer For NEMA 44*D
CS23502-
J220NEMA44
1
Motor spacer For NEMA 50*D
CS23502-
J220NEMA50
Motor spacer For IEC FF-600
CS23502-
J220IEC60
Motor spacer For IEC FF-740
CS23502-
J220IEC74
235-2 Plate, motor spacer CS23510-J170 2
235-3 Hexagon socket head cap screw M6×15 NB35406-015 8
739 Hexagon socket head cap screw M16×60 NB35416-060 8
740 Parallel pin
13 dia.×65 with female
thread
NE2313-065A 2
● As for the part code of the O-ring, the material of the standard specification is HNBR
and the material of the explosion-proof for propane specification is FKM.
For O-rings material other than HNBR or FKM, the part code No. are differ depending
on the material.
For customers using O-rings other than the standard material, contact
before purchasing the O-ring.
