Screw Compressor J-series 7.1 Development View and Configuration Table of the Parts
7-20
Part
No.
Part name
280J
Type, etc.
Part code No. Quantity/unit
Explosion proo
Standard for Propane S M L
100-1 O-ring JIS B2401 P110 PAH80-110 PC11-110 1
100-2 Mating ring 1
100-3 Rotating ring 1
100-4 O-ring AS568A-239 PAH82-239 PC62-017 1
100-5 Hexagon socket set screw M8×9 1
120 Assembly, unloader indicator 1
137 Dial plate, unloader indicator CS13700-J170 1
234 Name plate 1
237-1 Torsional slip washer M CS23700-J280M 1
237-2 Torsional slip washer F CS23700-J220M 1
246 Guide, unloader slide valve 1
247 Hexagon socket head cap screw M10×110 NB35410-110 4
248 Spring lock washer
Hexagon socket
head cap screw
M10
ND330-10 4
249 Parallel pin 13 dia.×100 NE2013-100 2
250-1 Thrust washer, male rotor CS25000-J280 1
250-2 Thrust washer, female rotor CS25000-J220 1
267 Spring lock washer
Hexagon socket
head cap screw
M10
ND330-10 9
289
Slide valve S, Vi 1 — —
Slide valve M, Vi — 1 —
Slide valve L, Vi — — 1
292
Push rod S, Vi CS29200-J280S 1 — —
Push rod M, Vi CS29200-J280M — 1 —
Push rod L, Vi CS29200-J280L — — 1
293 Spiral retaining ring FRSN-75 NGFR-75 2
294 Piston, Vi CS29400-J280 1
295 O-ring JIS B2401 P85 PAH80-085 PC11-085 1
296 Cylinder, Vi 1
297 Partition plate, unloader cylinder CS29700-J280 1
298 O-ring JIS B2401 G230 PAH81-230 PC12-230 1
299-1 O-ring JIS B2401 G135 PAH81-135 PC12-135 1
299-2 O-ring JIS B2401 G260 PAH81-260 PC12-260 1
325-1 O-ring JIS B2401 P58 PAH80-058 PC11-058 3
325-2 Back-up ring for O-ring SUN-2BP 58 PBP21-058 2
396-1 Liner M for thrust adjustment (Service part)
396-2 Liner F for thrust adjustment (Service part)
420
Unloader spacer S CS42000-J280S 1 — —
Unloader spacer M CS42000-J280M — 1 —
421 O-ring JIS B2401 P58 PAH80-058 PC11-058 2 —
432 O-ring JIS B2401 G165 PAH81-165 PC12-165 4
433 O-ring JIS B2401 G130 PAH81-130 PC12-130 4
446 Grooved pin
200***
Key for balance
piston
CS03100-200 1
451
Push rod gland for unloader slide
valve
CS45100-J280 1
458-1 Plug R1 1/4 NF06-032 1
458-2 Plug R1/2 NF06-015 4 4 3
459 Plug R1/2 NF06-015 1
528 Sleeve, oil seal 320*** CS52800-320VD 1
529 Hexagon socket set screw M6×8 NA83606-008 2
537 Bush, P14 type O-ring CS53700-J170 2
591 Parallel pin
16 dia.×70 with
female thread
NE2316-070A 2
605 Plug R1/2 NF06-015 1
607-A Plug R1/8 NF06-004 1
607-B Plug R1/4 NF06-008 1
607-C Plug R1/4 NF06-008 1
To Next Page
