MZ electronic EV-020 - Page 12

EV-020 Rev. 11 – 2014
English
25
Table 1 - Standard and Project X.. series sensor
(magnet and sensor placed on barbotin)
Table 2 - 1000 – 1500 – 2000W Project series sensor
(magnet and sensor placed on motor
)
Chain Type Number of recesses
Gipsy Circumference
(cm)
Gipsy Circumference
(inches)
6 22 9
6 mm
9 34 13
7 mm 6 25 10
5 24 9
6 28 11
7 33* 13
8 mm
8 38 15
5 31 12
10 mm
6 36 14
5 36 14
12 mm
6 43 17
13 mm 6 46 18
14 mm 5 42 16
* factory settings of instrument
Type
Gipsy
Circumfer. (cm)
Reduction
ratio
Number of
recesses
Chain type
(mm-inches)
Reduction
Factor
30 1:52 6 8-5/16”HT
30 1:52 5 10 DIN 766
57*
31 1:52 5 10 ISO-3/8”HT 59
Project 1000
34 1:52 9 6 65
30 1:70 6 8-5/16”HT 43
30 1:70 5 10 DIN 766 43
31 1:70 5 10 ISO-3/8”HT 44
Project 1500
36 1:70 5 12 ISO-13 DIN 766-7/16”HT 51
39 1:75 6 3/8”HT 52
40 1:75 6 3/8”Proof Coil 53
41 1:75 6 10 DIN 766-3/8”BBB 54
44 1:75 7 10 ISO 58
45 1:75 5 14 ISO 60
46 1:75 6 12 ISO-13 DIN 766 61
Project 2000
47 1:75 5 13 DIN 764 63
* factory setting of instrument
