MZ electronic EV-020 User Manual

EV-020 Rev. 11 – 2014
English
20
Once the initialisation procedure is complete, the main page will appear.
Stop
V=11.6
0.0
ft
0.0 ft/m
STATUS
SPEED'
ICONS
COUNT
MONITORING
metres / feet
feet / minute
metres / minute
Where:
STATUS: indicates the status of the instrument and any failure.
SPEED’: indicates the chain speed during hoisting or lowering in meters per minute or feet per minute.
COUNT: indicates the measurement of the chain lowered (in metres or feet).
MONITORING: indicates the power supply voltage.
ICONS: this is the part of the display bearing the icons that indicate the hoisting or casting of the anchor
and any failure.
When the instrument is turned on for the first time, it will set up as programmed in the factory (see table).
Parameter Default value
Up Alarm 3.0 metres
Auto Down Off
BackLight Time 30 seconds
Units of measurement Metres/centimetres
Chain Measure 0.0 metres
Barbotin Circumference 33 cm
Sensor type unknown
Keyboard Beep Yes
Language Italian
Works Hours 0
Division factor 1
Chain counter setting menu
Hold down the
(ON) key for six seconds
to access the instrument setting menu. The
following page will appear on the display:
Menu
M e a s u r e
A l a r m s & F u n c t i o n
S e t t i n g s
L an g u a g e
S e n s o r C a l i b r a t i o n
Use the (DOWN) and (UP) keys to
move around the menu options.
Menu
L an g u a g e
S e n s o r C a l i b r a t i o n
Te s t s
E x i t
Once you are positioned on the item to be modified press the (ON) key to confirm your
choice.
Use the (DOWN) or (UP) keys to move from one parameter to another.
Once one is positioned on the parameter press the (ON) key to enable modification.
According to the type of parameter, using the (DOWN) and (UP) keys it is possible to
reduce/increase the value of the same or disable/enable the function.
