MZ electronic EV-020 User Manual

EV-020 Rev. 11 – 2014
English
16
Description
The EV-020 chain counter displays the length of chain let out or down, expressed in metres or feet and
the speed of the same.
Technical data
Power supply from 10 to 30 V DC
Current intake min. 5 mA – max 50 mA
Protection rating IP65
Operative temperature 0 / +70 °C (32 / 158 °F)
Graphic display 128 x 64 pixels
Max. chain length 999 metres – 999 feet
Size (mm) 145 x 50 x 24
Weight (g) 450*
* with cable
Warning
CONNECT ONLY TO A DC POWER SUPPLY.
General notes
The EV-020 chain counter must be used solely for the purposes described herein, i.e. to operate and
display the number of metres/feet of chain let out by an anchor windlass. Any other use is to be
considered improper.
Any tampering with the instrument will result in immediate voiding of the warranty.
Components
T
he package contains:
• chain counter with extensible cable and fastening kit (1 bracket with 2 screws);
• 6-pole connector tap with gasket, 4 fastening screws with spacer rings and plug;
• instructions for use.
Installation
O
n a few models of anchor windlass the sensor and the magnet are already installed (chain
counter setting). Therefore, the operations described below are not necessary.

MZ electronic EV-020 Specifications

General

Brand	MZ electronic
Model	EV-020
Category	Cash Counter
Language	English
