Nabco Opus Control Wiring And Programming Installation Manual

19 of 32
www.NabcoEntrances.com OpusControlWiringandProgrammingInstallaonManual
Rev. 10-20-17 P/N C-00139
SECTION 11.2: Acvaon using ON/OFF/Hold-Open Switch
DN 1330
1 12VDC +12VDC
2 GND Common for 12V and Signals
361Interior Ac va on
462Exterior Ac va on/Programmable Input
56BSwing Door Con nuous Safety (door mounted, swing side Safety Sensor)
Slide Door Holding Beam
6SWL Swing Door Safety with Lockout (overhead, swing side safety sensor)
Slide Door Sidelite Sensor
7 Out1 Programmable Output
1413121110
98
7654321
1413121110
98
7654321
Exterior Push-Plate
Interior Push-Plate
COM
N.O.
COM
N.O.
All Devices Must Be
N.O. Dry Contact
Powered Activation Devices
(sensor, card reader, radio receiver, etc.)
Powered Activation Devices
Non-Powered Activation Devices
WARNING!
Total Power Consumption Of All Sensors And Powered Activation
Devices Must Not Exceed 750 mA
All Device Outputs Must Be
N.O. Dry Contact
COM N.O.
PWR+ PWR-
COM N.O.
PWR+ PWR-
Exterior ActivationInterior Activation
RADIO
RECEIVER
7
6
54
321
3
2
4
RED
BLUE
BLACK
1413121110
98
8
WHITE
Off
Hold Open
On
Off
7
6
54
321
3
2
4
1
RED
BLUE
BLACK
1413121110
98
8
WHITE
Off
Hold Open
On
Off
NOTE:
If not using ON/OFF/HOLD OPEN switch,
change "Input BA Circuit" to "Normally Open
