45.
1. Lace one end of the line through both holes of the stop
block.
2. Then over the middle of the block and through the
loop just created.
3. Feed the line back through the same loop but don’t
pull it through entirely. This should leave a loop.
4. Tie the used end of the rope of with a figure 8 knot.
6.3. Can’t miss trapeze wires (optional)
Front Back
5. Feed the free end of the line through the eye in the
trapeze wire.
6. Tie this end to the metal part of the can’t miss trapeze
ring using a overhand knot.
7. Tie the line o with a figure 8 knot.
5mm
Trapeze line 2x
